ZigBee/24G MmWave Radar Human Presence Motion Sensor With 16A Relay Luminance Detection 110/220V Tuya Smart Life Home

Specifications: Network: ZigBee input: 85-240VAC. Working temperature: -10℃~+50℃ Sensitivity: 1-9(default 7) 5.8G Beam Angle:120X120 24G Beam Angle:115X115° 5.8G Sensing distance: 0-11m(default 6m) 24G Sensing distance: 2.5-10m(default 7m) 5.8G Sensing radius: 2.5-3m(Presence),4～5.5m(motion). 24G Sensing radius: 2-3m(Presence),4～4.5m(motion). Illuminance Sensor: 0～500 Lux（The approximate brightness of the environment in which the sensor is located）. Departure Delay: 0.5s～25 min；It is recommended to set it to no less than 15S. Otherwise, detection may be missed. Transmitting Power: 3～5 dBm(5.8G), 10dBm(24G). Working Humidity: 5～90% RH(No Condensation). Protection Level: IP20. Relay Load: Resistive load≤3000W LED≤300W. Circular Size: Φ105mm*28mm/Φ4.13inch*1.1inch Ceiling mount Size: Φ75mm*61mm Φ2.95inch*2.4inch Installation Principles 1. In hallways, changing rooms, kitchens, and other indoor areas, sensors should be installed in the center as much as possible and firmly fixed. 2. In bathrooms and toilets, sensors should be installed 0.4-0.6m in front of the top of the toilet/squatting position, away from doors, windows, and exhaust fans. 3. Living room/dining room/conference room: Located 0.5-1m in front of the sofa, directly above the table. 4. Bedroom and study: Directly above the bed, within 0.6-1.5 meters behind the table. 5. Glass and gypsum board partition: The sensor should be as close to the solid wall as possible. If it's all glass and gypsum boardWall, sensors can be installed in the center and set with appropriate Detection Range, Entry Distance Indentatio, and Sensitive to resolve situations where glass and wall surfaces are detected. 6. Sitting, squatting, and standing still scene: sensor celling mounted, 0.4 in front of the head top-0.8m position. It is not suitable to install directly in the overhead position. 7. Dense deployment scenario: The linear spacing distance between sensors should not be less than 5m.
